Osprey 827e - dual channel capture, 1 HD/SD SDI and 1 DVI-I
Inputs: 1 x SDI, 1 x DVI-I
BNC Input Format: 3G/HD/SD SDI, DVB-ASI
DVI Input Format: HDMI, VGA, Component, Composite, S-Video
Audio: All the features of the 800a built in
PCIe® (x4): x4, x8, or x16 slots
Osprey 815e - single channel capture, 1 HD/SD SDI
Inputs: 1 x SDI
Connector: HD/SD SDI
Audio: Embedded SDI (4 stereo pair per channel) NOTE: Add the 800a for more audio options.
Video Loop-out: 1 X SDI
PCIe® (x4): x4, x8, or x16 slots
Osprey 810e - single channel capture, 1 DVI-I
Inputs: 1 x DVI-I
Format: DVI, HDMI, VGA, Component, Composite, S-Video (adapters included)
Audio: HDMI (4x Stereo LPCM) NOTE: Add the 800a for more audio options.
PCIe® (x4): x4, x8, or x16 slots
Osprey 811e - single channel capture, 1 HDMI
Inputs: 1 x HDMI
Connector: HDMI
Audio: HDMI (4 x Stereo LPCM) NOTE: Add the 800a for more audio options.
PCIe® (x4): x4, x8, or x16 slots
Osprey 821e - dual channel capture, 2 HDMI
Inputs: 2 x HDMI
Connector: HDMI
Audio: HDMI (4 x Stereo LPCM) per channel NOTE: Add the 800a for more audio options.
PCIe® (x4): x1, x4, x8, or x16 slots
|
 |
